Universal
Test machine(with extensometer)
|
|
Art.No.
|
TR-UTM-8001
|
|
Max load
|
5KN，10KN, 20KN
|
|
Accurate grade
|
1 % /0.5 %
|
|
Effective measuring range
|
0.2％～100％（1grade）/0.4％～100％（0.5 grade）
|
|
Measuring accuracy
|
Display the value ±1％/Display the value±0.5％
|
|
Units
|
Kg, N, LB, TON, can
be exchanged.
|
|
Tester resolution
|
Max.load 1/200000,don't step
inside and outside,and the entire resolution remain the same
|
|
Effective width of test
|
400mm(customizable)
|
|
Effective tensile space
|
500,600,800mm(customizable)
|
|
The test speed range
|
0.001～200mm/min ; 500mm/min
(1000mm/min is option)
|
|
Power system
|
Power system Panasonic AC Servo
Motor + Driver + high-precision ball screw
|
|
Deformation of measured system(according to the requirements)
|
Min span :10mm, Max range of
deformation ：800mm
|
|
Extended deformation ：Min span: 25mm、50mm、100mm, range of deformation ：5mm、10mm、25mm
|
|
Accuracy of measured deformation
|
Tolerance :±0.5％ （according to requirement of customer to choose
the larger or small deformation）
|
|
safety
|
Electronic-limit protection
|
|
Testing platform moving device
|
Fast /slow two speeds to
control，can
jog
|
|
Power
|
0．4KW（depending
on different demand of force, using different motor）
|
